GAS ANESTHESIA SYSTEMS

Modern gas anesthetic agents, particularly Isoflurane, are less irritating to tissues and less likely to cause long lasting damage than injectables. Gas anesthetic systems make it easier to control the depth of anesthesia.   Isoflurane and Sevoforane are nonflammable and can easily be used in conjunction with the common Ventilators (Respirators) such as the renown AUTOVENT or similar. The systems here shown are intended for use with Isoflurane accordingly mixed with O2 and N2O, on request it is even provided the CO2 flow column kit. Vaporizers are different for Isoflurane and Sevoforane and both  have max. 5% adjustment which also enable to ventilate large size animals. The gas anesthesia systems can be assembled in different configurations:  System with Recycling, Open Circuit, Table Top Unit. The Open Circuit system is especially intended for rats and small rodents. In these systems the recycling components are not included (flow of gas escaping from the end of the Vaporizer outlet tube), thus the Researcher has to use a Scavanger (FLUOVAC) such that described below. Any system is provided with suitable animal Masks and Tank Pressure regulators. Halotane units still available.

Code  2305  Recycling Gas anesthesia system (specify Isoflurane or others)

Code  2310  Open Circuit Gas anesthesia system (specify Isoflurane or others)

Code  2315  Table Top  Gas anesthesia system (specify Isoflurane or others)

Code  2345  Automatic AUTOVENT Respirator

The picture above shows a complete Gas anesthesia system mounted on a trolley.

This assembly also includes escaping gas alarm, ventilators,  possibility of open or recycling circuit and a 3 way flow column kit (O2, CO2, N2O).

FLUOVAC UNIT

The Fluovac Isoflurane/Halotane Scavanger unit allows continuous flow gas anesthetization without exposin the Operator to escaped gases.

It recaptures the gases by vacuum and draws them through a disposable Fluosorber filter Canister which effectively remove all the gas (Hunter, Glen and Butcher, Laboratory Animals 18: 42-44; 1984). The disposable filters, ordered separately, initially weights about 1200 grams. It will absorb 200 grams of gas and must discarded when it reaches 1400 grams in weight.

Code  2335  Scavanger FLUOVAC unit

Code  2340  Pkg. of 6 Fluosorber Canister for    Fluovac

Picture above shows recycling circuit

OXYGEN CONCENTRATOR

It can replaces High Pressure TANKS in Gas Anesthesia Systems, isolated organ baths, ventilator air input and more and more.

Save money for the future: 02 or AIR TANKS not more needed

It is enough a normal plug (220V - 50 Hz) where you connect the concentrator to obtain: medical oxygen (pure O2 over 92%) with a maximum flow of 5 lt/min for each of the two Flometers or medical air with a maximum flow of 10 lt/min (single channel).

Size: 495 (L) x 475 (P) x 730 (H) mm - Weight: 32 kg

Code O2-GEN: unit with 2 output ch. pure O2 over 92%

Code O2-GEN + AIR: unit with 2 outputs pure O2 over 92% and a third MEDICAL AIR channel

INDUCTION CHAMBER FOR GAS ANESTHESIA

The Rodent Induction chamber measures 25 x 13 x 14 cm.

It is provided with a sliding cover  and the transparent acrylics allows the animal to be kept under constant observation.

Two tube connectors enables easy linking to any Gas Anesthesia System and/or Scavanger Fluovac Unit.

Also available a bigger chamber for larger (Rabbit) animals (40 x 22 x 21 cm.)

Code AB-1  Induction chamber for Rodent    26 x 11 x 11 cm

Code AB-2  Induction chamber for Rabbits    26 x 21 x 21 cm

GAS ANESTHESIA MASKS  for STEREOTAXIC

These Adapter Masks enable the Scientist to  use Gas Anesthesia on Rats and Mice on most common Stereotaxic Instruments without personal exposure to the gas. Available in two different sizes for Rats and Mice

Code 51610  Gas Anesthesia Mask for Rats

Code 51609  Gas Anesthesia Mask for Mice

Code 50067  MRI Compatible Respirator

Gas Anesthesia and MRI small animal compact respirator

Non-magnetic pneumatic valves  -  Dependable all-electronic ventilator - Wide tidal volume and rate range - Mice to Guinea pig size - Safe with oxygen and anesthesia - Direct readout of volume and rate.

This newest generation of the pressure-fed small animal respirator that can be used during MRI imaging. The MRI respirator is supplied with a sophisticated external, remote-controlled high speed pneumatic valve system. The control unit is separate from all non-metallic remote components, ensuring safety in operation. It features direct setting and readout of breaths/min, tidal volume, and other parameters for easy setup and monitoring. These respirators function on "flow-time"; i.e., inspiration flow is set and run for a known time, producing a known volume. A serial data output is standard. Requires a separate source of compressed air or helium for operation of the pneumatic valves (not included.)

Tidal Volume :   0,1 to 50 ml/stroke

Respiration rate : 5 – 150 Breaths/minute
